Helix IK W8 DVC2
199.00 лв.
8″ (20см) субуфер Helix / 300W RMS / 2 x 2 Ohm / с включена предпазна решетка
- Описание
- Допълнителна информация
- Отзиви (0)
Описание
Описание
Stunning bass performance out of compact dimensions
With the new KW chassis, we’re expanding our IMPACT subwoofer lineup, offering powerful drivers for use in very compact enclosures. Especially when it comes to the most efficient usage of available space in the vehicle regarding an individual enclosure design, these woofers create completely new installation possibilities without ever compromising the acoustic performance.
Clever down to the last detail
The extremely stiff cone made of hand-scooped paper fibers in connection with the heavy-duty driver system not only converts amplifier power easily and without compression effects into loads of sound pressure, but also scores sonically with subtle beats.
Flexible connection – 2 x 2 or 1 x 2 Ohms
The chassis are available as 1 x 2 Ohms (SVC2) or 2 x 2 Ohms (DVC2) version. Thus, these subwoofers always offers the right solution for every amplifier configuration to get the maximum performance out of it – whether mono, 2-channel or even multi-channel amplifier.
„All inclusive“ for self-made enthusiasts
In addition, the solid protective grille and gasket are also included. For optimal bass performance in DIY installations you can find recommendations for sealed and vented enclosures with all parameters such as net volume, port tuning frequency as well as DSP settings in our technical data sheet.
2 години гаранционен срок.
Препоръчителни боксове
Затворен обем
Net volume 8 L
Lower limiting frequency (-3dB) 50Hz
Recommended DSP settings
Recommended „self-define“ highpass filter with 50 Hz cut-off frequency and Q = 1.5,
additional EQ filter 115 Hz / Q = 1.0 / -2.5 dB
Отворен обем
Net volume 8 L
Port diameter ø 60 mm / 2.36″
Port area 28 cm²
Port length 42 cm / 16.5″ (angled port)
Port tuning frequency
Fb 43 Hz
Lower limiting frequency (-3dB) 45 Hz
Recommended DSP settings
Recommended „self-define“ highpass filter with 43 Hz cut-off frequency and Q = 1.5,
additional EQ filter 120 Hz / Q = 0.8 / -3.5 dB
Характеристики
- – Изключително здрава ръчно изработена мембрана
- – Двойно охлаждане на намотката с минимален компресионен ефект
- – Гумен предпазител над магнитната система с Helix лого
- – 2х2Ohm намотки за различни конфигурации при свързване
- – Солидни push терминали
- – Мощна магнитна система за компактни басрефлексни боксове
- – Метална предпазна решетка в комплекта
Технически данни
- – Power RMS / max. P 300 / 600 Watts
- – Impedance Z 2 x 2 Ω
- – DC resistance Re 2 x 1.6 Ω
- – Resonance frequency Fs 37 Hz
- – Mechanical Q factor Qms 3.56
- – Total Q factor Qts 0.41
- – Compliance Cms 262 μm/N
- – Equivalent air volume Vas 17 L
- – Force factor B*I 10.7 Tm
- – Efficiency 1 W / 1 m SPL 86.0 dB
- – Cone area Sd 219 cm²
- – Mechanical resistance Rms 4.54 kg/s
- – Voice coil winding height 24 mm
- – Max. linear excursion Xmax +/- 8.0 mm
- – Outer diameter ø 213 mm / 8.38″
- – Installation diameter ø 182 mm / 7.17″
- – Installation depth 101 mm / 3.98″
- – Electrical Q factor Qes 0.46
Какво има в кутията
1бр. субуфер Helix IK W8
1бр. метална предпазна решетка
Техническа документация
