Key Features
| DAB+ Digital radio tuner built-in |
| Bluetooth handsfree & audio streaming built-in |
| Front USB + AUX-in with dust cover |
| MP3/WMA/WAV/FLAC playback |
| KENWOOD Remote app ready (available in Play Store) |
| DSP, DTA, 3-Way X’over & 13-band EQ built-in |
| 1x RCA Preouts (2,5V) |
| Red key & White display illumination. |
| English/French/Russian & Spanish GUI language |
| Short body for easy installation |
Display Features
| Display Type |
Liquid Crystal Display (LCD) |
| Display Layout |
1 line 13 Segments x 13 Digit |
| Vertical Aligment Liquid Crystal Display |
Yes |
| Display Illumination |
White (LED) |
| Dimmer Control |
Manual / Set by Timer |
| Brightness control |
0 – 31 steps |
| Demo Mode |
Yes |
| Menu text in selectable language |
English(default) / Spanish / French / Russian |
| TAG Language Display |
English, Spanish, Russian & Greek |
Cosmetics features
| Front/edge |
Black Injection |
| Dress plate |
Black Injection |
| Preset key finish |
Black Injection |
| Escutcheon finish |
Black Injection |
| Triangle Illumination |
Red LED |
| Front terminals dust cover |
Yes |
| Key illumination |
Red LED |
| Illuminated front USB port |
Red LED |
| Display illumination |
White LED |
| Brightness Control (Key) |
0 – 31 step |
| Brightness Control (Display) |
0 – 31 step |
| Dimmer Control (Key) |
Manual / Set by Timer |
| Dimmer Control (Display) |
Manual / Set by Timer |
CE DAB tuner features
| DAB+ tuner built-in |
Yes |
| Digital Radio Certification Mark |
Yes |
| Intelligent seek |
Yes, (Service, Ensemble & Component) |
| Tuning mode / Seek mode |
Auto1/Auto2/Manual |
| Service preset |
6 ch * 3 bank presets, |
| Service list by alphabet order |
Yes |
| Preset list |
Yes |
| Alphabet Search |
Yes |
| Related service |
Yes |
| Audio interrupt standby by PTY |
Yes |
| Audio interrupt standby by announcement |
Yes |
| DAB-RDS integrated TI |
Yes |
| Traffic Information |
Yes |
| DAB priority |
Yes |
| PTY (Programme Type) search |
Yes |
| PTY (Programme Type) watch |
Yes |
| Soft linking |
Yes |
| Antenna power supply on/off switch |
Yes |
| DAB antenna included |
Yes, SMB terminal |
Audio Features
| Maximum Output Power |
50W x 4 |
| MOSFET Power IC |
Yes |
| Auxiliary input |
Yes, Front, Mini-jack |
| Pre-out |
1 RCA |
| Pre-out Output Level |
2.5V |
| Preout Rear / Subwoofer Switchable |
Yes |
| Subwoofer Reference Level Adj. |
Yes |
| 2-Way X’over network |
Yes |
| 3-Way x’over (bi-amp connection) |
Yes |
| Balance/Fader/Loudness Control |
Yes |
| Loudness Control |
Off / LV1/ LV2 |
| Bass Boost Circuit |
Off/+1/+2/+3/+4/+5 |
| Graphic Equalizer + Preset |
13-Bands Graphic Equalizer with 8 Presets. |
| Digital Sound Processor (DSP) Built-in |
Yes |
| Digital Time Aligment (DTA) |
Yes |
| Low- & High-pass Filter |
Yes |
| Speaker Size Control |
Yes |
| Sound Reconstruction |
Yes |
| Space Enhancer |
Yes |
| Realizer |
Yes |
| Stage EQ |
Yes |
| Drive EQ |
Yes |
| Sound Elevation |
Yes |
Bluetooth General Features
Tuner Specifications
| FM range: 87.5Mhz – 108MHz (50Khz step) |
Yes |
| FM Usable Sensitivity |
0.56μV/75ohm (S/N 30dBf) |
| FM Quieting Sensitivity |
1.58μV/75ohm (S/N 46dBf) |
| FM Frequency Response |
30Hz ~ 15kHz (± 3dB) |
| FM Signal to noise ratio (Mono) |
68dB |
| FM Stereo Separation (1kHz) |
40dB |
| MW range: 531kHz – 1611kHz (9kHz step) |
Yes |
| MW Usable Sensitivity |
28.5μV |
| LW range: 153kHz – 279kHz (9kHz step) |
Yes |
| LW Usable Sensitivity |
45μV |
DAB Tuner specifications
| Band III – Frequency range |
174.928 MHz – 239.2MHz |
| Mode |
I, II, III, IV |
| Sensitivity |
– 100dBm |
| Signal to noise ratio |
90dB |
| DAB Aerial Connector Type |
SMB |
| Output Voltage |
12V (11V to 16V allowable) |
| Maximum Current |
< 100 mA |
USB Specifications
| USB Version compatibility |
USB 1.1 / 2.0 full speed |
| File System |
FAT 32 / 16 / 12 |
| Maximum Supply current |
1500mA |
| MP3 Decode |
Compliant with MPEG-1/2 Audio Layer-3 |
| WMA Decode |
Compliant with Windows Media Audio |
| WAV Decode |
Linear – PCM Files |
| flac Decode |
FLAC files up to 96kHz/24bit |
| Frequency Response |
20Hz – 20kHz |
| S/N Ratio |
99 dB (1kHz) |
| Dynamic Range |
93dB |
| Channel Separation |
90dB |
Audio Specifications
| Maximum Power |
50W x 4 |
| Output Power (DIN45324,+B=14.4v) |
22W x 4 |
| Preout Level |
2500mV / 10kOhm, |
| Preout Impedance |
≤ 600Ohm |
| Speaker Impedance |
4Ohm ~ 8Ohm |
| AUX Frequency Response |
20Hz ~ 20kHz (±1dB) |
| AUX Maximum Input Voltage |
1000mV |
| AUX Input Impedance |
30kOhm |
| Graphical Equalizer |
13-Band |
| G. EQ. Frequency (Hz) |
62,5/100/160/250/400/630/1k/1k6/2k5/4k/6k3/10k/16k |
| G. EQ. Gain (dB) |
-7 / … / +7 |
| Subwoofer Level (dB) |
-50 dB to +10dB |
Bluetooth specifications
| Technology |
Bluetooth V4.2 |
| Frequency |
2.402 – 2.48 GHz |
| Output power |
+4dBm(max), power class 2 |
| Maximum range |
Line of sight approx. 10 meter |
| Handsfree profile (HFP) |
Yes, V1.7.1 |
| Serial port profile (SPP) |
Yes |
| Advanced audio distribution profile (A2DP) |
Yes |
| Audio Codec |
SBC |
| Audio/Video remote control profile (AVRCP) |
Yes, V1.6.1 |
| Phonebook access profile (PBAP) |
Yes |
Accessories
| Release keys |
2 pieces |
| Escutcheon |
Yes |
| Installation Sleeve |
Yes |
| DC cord (Mitsumi to ISO) |
20 cm |
| DAB antenna |
with 3 m cable |
| Handsfree Microphone |
with 3 m cable |
| Multi-Language Instruction Manual Included |
Quick-Guide |
| Manuals Downloadable |
Yes |
General Specifications
| Operating voltage |
14.4V (10.5 ~ 16V Allowable) |
| Maximum Current Consumption |
10A |
| Dimensions (WxHxD) |
182 x 53 x 100mm |
| Weight |
700 gr. |
