Описание
Output power RMS / max. | |
– @ 4 Ohms | 4 x 65 / 130 Watts |
– @ 2 Ohms | 4 x 90 / 180 Watts |
– @ 1 Ohm | – |
– bridged @ 4 Ohms | 2 x 180 / 360 Watts |
– bridged @ 2 Ohms | – |
Amplifier technology | Class AB |
Inputs | 4 x RCA / Cinch |
4 x Highlevel speaker input | |
1 x Remote In | |
1 x Remote control input | |
Input sensitivity | RCA / Cinch 0.5 – 6 Volts |
Highlevel 1 – 14 Volts | |
Input impedance RCA / Cinch | 30 kOhms |
Input impedance highlevel | 12 Ohms |
Outputs | 4 x Speaker output |
Output voltage RCA / Cinch | – |
Signal converter for digital input | – |
Frequency response | 10 Hz – 50.000 Hz |
Bass boost | 0 – 12 dB / 45 Hz |
Highpass | 15 Hz – 4,000 Hz adjustable |
Lowpass | 40 Hz – 4,000 Hz adjustable |
Bandpass | 15 Hz – 4,000 Hz adjustable |
Subsonic | – |
Phase | – |
Slope high- / lowpass | 12 dB/Oct. |
Slope subsonic / lowpass | – |
Signal-to-noise ratio digital input | – |
Signal-to-noise ratio analog input | 108 dB (A-weighted) |
Distortion (THD) | 0.02 % |
Damping factor | 65 |
Operating voltage | 9.6 – 16 Volts |
Idle current | 1000 mA |
Fuse | 2 x 25 A Maxi-fuse (APX) |
Additional features | Active, adjustable crossover, bass boost, input mode switch, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), optional cable remote control |
Dimensions (H x W x D) | 53 x 320 x 230 mm |
