– High-End SQ amplifier
– Shielded dual power supply
– Discretely constructed MOS-FET amplifier section
– 1-ohm stable stereo / 2-ohms stable in bridged mode
– Smoothly variable BIAS adjustment
– Variable input sensitivity
– Capsulated potentiometers
– Wide range high pass and low pass filter
– Filter range multiplication switch (x10)
– Wide frequency range for high resolution music (10 Hz – 50 kHz)
– Soft start delay
– Operation and protection indicator
– Start-Stop capability (9 -16 Volt)
– Overheat and short circuit protection
– Low distortion Burr-Brown OPA2134PA operation amplifier
– Ground Zero exclusive Mundorf Mcap® capacitors
– Solid and high efficient black anodized heatsink
– White illuminated lasered glass logo plate
– Shielded dual power supply
– Discretely constructed MOS-FET amplifier section
– 1-ohm stable stereo / 2-ohms stable in bridged mode
– Smoothly variable BIAS adjustment
– Variable input sensitivity
– Capsulated potentiometers
– Wide range high pass and low pass filter
– Filter range multiplication switch (x10)
– Wide frequency range for high resolution music (10 Hz – 50 kHz)
– Soft start delay
– Operation and protection indicator
– Start-Stop capability (9 -16 Volt)
– Overheat and short circuit protection
– Low distortion Burr-Brown OPA2134PA operation amplifier
– Ground Zero exclusive Mundorf Mcap® capacitors
– Solid and high efficient black anodized heatsink
– White illuminated lasered glass logo plate
| Number of channels : | 4 / class AB > A |
| RMS power output (14,4V, 1% THD): | |
| Power output in 4ohm: | 4 x 125W |
| Power output in 2ohm: | 4 x 225W |
| Power output in 1ohm: | 4 x 350W |
| Power output in bridge mode 4ohm: | 2 x 450W |
| Power output in bridge mode 2ohm | 2 x 700W |
| Power output in bridge mode 1ohm: | – |
| Highpass filter: | 20 Hz – 400 Hz (200 – 4000Hz switch) |
| Lowpass filter: | 20 Hz – 400 Hz (200 – 4000Hz switch) |
| Subsonic filter | 20 Hz – 400 Hz |
| Remote control: | Yes |
| Bass boost: | No |
| Input level: | 1 – 6V |
| Hi Level Input: | Yes |
| Distortion: | – |
| Max. current draw: | – |
| Dimensions: | 40,2 x 6,05 x 22,2см |
| Fuses: | 3 x 40A |
