Helix P1T
139.00 лв.
There’s definitely not much to say about this tweeter – the fantastic sonic performance thrills both the press and end-users since many years. Despite the decent appearance this driver is a „giant“ with respect to sound quality. Like its predecessor it easily outperforms competitor products and defines the standard in its class. Precision, resolution and tonality have a short and simple name – P 1T.
Features:
– 1″ / 25 mm tweeter with high efficient neodymium magnet and hand-coated silk dome for balanced, natural sound reproduction and lowest compression effects
– Including installation and mounting equipment
– Lowest possible production tolerances and solely use of best materials
- Описание
- Допълнителна информация
- Отзиви (0)
Описание
| Power RMS / max. | P | 100 / 200 Watts (highpass > 3,000 Hz at 12 dB/Oct.) |
| Impedance | Z | 4 Ω |
| DC resistance | Re | 3.4 Ω |
| Frequency response | 2,500 Hz – 25,000 Hz | |
| Resonance frequency | Fs | 1,500 Hz |
| Efficiency 1 W / 1 m | SPL | 91 dB |
| Voice coil diameter | ø | 25 mm |
| Cone area | Sd | 4.9 cm² |
| Moving mass | Mms | 0.3 g |
| Cone material | Silk dome | |
| Outer diameter | ø | 58 mm / 2.28″ |
| Installation diameter | ø | 49.3 mm / 1.95″ |
| Installation depth | 15 mm / 0.60″ | |
| Recommended crossover frequencies for the highpass | ||
| Slope | Minimum crossover frequency | |
| 6 dB/Octave | 4,000 Hz | |
| 12 dB/Octave | > 3,000 Hz | |
| 24 dB/Octave | > 2,500 Hz | |
Допълнителна информация
| Тегло | 1 кг |
|---|---|
| RMS мощност | |
| Пикова мощност | |
| Размер | |
| Съпротивление |
