Описание
| Power RMS / max. | P | 100 / 200 Watts |
| Impedance | Z | 4 Ω |
| DC resistance | Re | 3.5 Ω |
| Resonance frequency | Fs | 56 Hz |
| Mechanical Q factor | Qms | 5.48 |
| Electrical Q factor | Qes | 0.54 |
| Total Q factor | Qts | 0.49 |
| Compliance | Cms | 571 μm/N |
| Equivalent air volume | Vas | 13.2 L |
| Force factor | B*I | 5.7 Tm |
| Efficiency 1 W / 1 m | SPL | 90 dB |
| Cone area | Sd | 129 cm² |
| Moving mass | Mms | 14.3 g |
| Cone material | Glassfiber-paper compound | |
| Mechanical resistance | Rms | 0.91 kg/s |
| Voice coil diameter | ø | 25 mm |
| Voice coil winding height | 12 mm | |
| Max. linear excursion | Xmax | +/- 3 mm |
| Outer diameter | ø | 165.5 mm / 6.50″ |
| Installation diameter | ø | 142 mm / 5.60″ |
| Installation depth | 67 mm / 2.64″ | |
| Recommended enclosure volumes | ||
| Sealed box | ||
| Net volume | 8 L | |
| Lower limiting frequency (-3dB) | 75 Hz | |
| Vented box | ||
| Net volume | 14 L | |
| Port diameter | ø | 50 mm / 2.00″ |
| Port area | 20 cm² | |
| Port length | 12.5 cm / 4.92″ | |
| Port tuning frequency | Fb | 48 Hz |
| Lower limiting frequency (-3dB) | 51 Hzka |
Допълнителна информация
| Тегло | 1 кг |
|---|---|
| RMS мощност | |
| Пикова мощност | |
| Размер |
