Helix IK W10 DVC2
249.00 лв.
10″ (25см.) субуфер Helix / 300W RMS/ 600W max / 2x2Ohm / включена решетка в комплекта
- Описание
- Допълнителна информация
- Отзиви (0)
Описание
Описание
Stunning bass performance out of compact dimensions
With the new KW chassis, we’re expanding our IMPACT subwoofer lineup, offering powerful drivers for use in very compact enclosures. Especially when it comes to the most efficient usage of available space in the vehicle regarding an individual enclosure design, these woofers create completely new installation possibilities without ever compromising the acoustic performance.
Clever down to the last detail
The extremely stiff cone made of hand-scooped paper fibers in connection with the heavy-duty driver system not only converts amplifier power easily and without compression effects into loads of sound pressure, but also scores sonically with subtle beats.
Flexible connection – 2 x 2 or 1 x 2 Ohms
The chassis are available as 1 x 2 Ohms (SVC2) or 2 x 2 Ohms (DVC2) version. Thus, these subwoofers always offers the right solution for every amplifier configuration to get the maximum performance out of it – whether mono, 2-channel or even multi-channel amplifier.
„All inclusive“ for self-made enthusiasts
In addition, the solid protective grille and gasket are also included. For optimal bass performance in DIY installations you can find recommendations for sealed and vented enclosures with all parameters such as net volume, port tuning frequency as well as DSP settings in our technical data sheet.
| Препоръчителни обеми |
||
| Затворен обем |
||
| Net volume | 12 L | |
| Lower limiting frequency (-3dB) | 53 Hz | |
| Басрефлексен обем |
||
| Net volume | 19 L | |
| Port diameter | ø | 70 mm / 2.76″ |
| Port area | 38 cm² | |
| Port length | 22 cm / 8.66″ | |
| Port tuning frequency | Fb | 43 Hz |
| Lower limiting frequency (-3dB) | 43 Hz | |
Характеристики
- – 10″ (25см) суббас с ръчно изработена хартиена мембрана и двойна намотка
- – Индивидуално Helix шаси с допълнителни вентилационни отвори за по-добро охлаждане
- – Двунамотков суббас с импеданс 2х2Ohm
- – Солидни push терминали
- – Мощна магнитна система за компактни басрефлексни боксове
- – Гумен предпазител над магнитната система с Helix лого
- – Метална предпазна решетка в комплекта
Технически данни
- – Power RMS / max. P 300 / 600 Watts
- – Impedance Z 2 x 2 Ω
- – DC resistance Re 2 x 1.6 Ω
- – Resonance frequency Fs 36 Hz
- – Mechanical Q factor Qms 4.50
- – Electrical Q factor Qes 0.43
- – Total Q factor Qts 0.39
- – Compliance Cms 218 μm/N
- – Equivalent air volume Vas 34 L
- – Force factor B*I 12.3 Tm
- – Efficiency 1 W / 1 m SPL 88.0 dB
- – Cone area Sd 333 cm²
- – Cone material Hand-scooped paper cone
- – Mechanical resistance Rms 4.56 kg/s
- – Voice coil diameter ø 50.8 mm
- – Voice coil winding height 24 mm
- – Max. linear excursion Xmax +/- 8.0 mm
- – Outer diameter ø 262 mm / 10.31″
- – Installation diameter ø 232 mm / 9.13″
- – Installation depth 126 mm / 4.96″
Какво има в кутията
1бр субуфер Helix IK W10
1бр метална предпазна решетка
1бр уплътнение
1бр инструкция
